Oxygen Generator Rau Ntses Farm

Oxygen Generator Rau Ntses Farm

NEWTEK Oxygen Generator For Fish Farm yog tsim los daws cov teeb meem oxygen deficiency hauv aquaculture, ib qho kev hem thawj tseem ceeb rau ntses thiab cw ciaj sia. Txais dav hlau + impeller dual- cuam tshuam aeration tech, nws ncav cuag 1.5-3m underwater aeration qhov tob, boosting oxygen dissolution efficiency los ntawm 30% vs cov qauv ib txwm-1 teev elevates 1000㎡ pas dej yaj cov pa oxygen los ntawm 3mg / L mus rau ntau tshaj 8mg / L.Equipped lub cev muaj zog (0.75KW-5.5KW), nws txuag 20%-25% zog. Ua los ntawm 304 stainless hlau thiab engineering yas, nws resists corrosion, pab 5-8 xyoo. Haum rau cov pas dej ntses, cw tank, kev lag luam aquaculture, nws txhim khu kev ciaj sia ntawm 15% -30%, accelerates kev loj hlob, thiab txiav kev pheej hmoo. Nrog IP68 waterproofing thiab kev ua haujlwm yooj yim, nws yog qhov kev lees paub zoo rau cov txiaj ntsig aquaculture.
Xa kev nug

Hauj lwm lawm

Kev tsis


Vim li cas xaivNEWTEKoxygen generators?


●Ultra-pab pa oxygen zoo: Dav hlau + impeller dual-effect aeration, 30% siab dua cov pa oxygen efficiency dua li cov qauv ib txwm muaj. Nce 1000㎡ ntses DO los ntawm 3mg / L mus rau ntau dua 8mg / L hauv 1 teev. Ib chav tsev npog 500-2000㎡, 360℃tsis muaj qhov chaw tuag, txiav cov khoom siv thiab cov ntses tuag los ntawm lub zos hypoxia.



●Zog - txuag: 0.75KW-5.5KW ntshiab tooj liab tsis muaj dej tsis muaj lub cev muaj zog, txuag 20%-25% zog vs aluminium core. Yeem DO detector rau pib / nres, zam kev ua haujlwm tsis zoo.



●Durable: 304 stainless hlau + engineering yas lub cev, corrosion / hnav-cov khoom tiv taus, 5-8 xyoo kev pabcuam hauv dej tshiab / me ntsis brackish. IP68 lub cev muaj zog, hnyav lub hauv paus rau kev ruaj ntseg, haum rau ib puag ncig hnyav.


●Yooj yim rau siv & tswj: Unbox, raus, txuas fais fab. Detachable core qhov chaw, niaj hnub tu nrog cov cuab yeej yooj yim (tsis xav tau cov kws tshaj lij).

Oxygen Generator For Fish Farm

product-171-40NTK93 Series PSA Oxygen Plant Model Xaiv
Tsis muaj. Cov qauv Peev xwm (Nm3 / h) Purity Lub zog noj ntawm 1Nm3 oxygen tsim (kw / h) Tus naj npawb ntawm cov fwj ntim hauv 12 teev (pcs) Tus neeg ua haujlwm xav tau
1 NTK-5 P 5 93%+-3% 3.54 10 2
2 NTK-10 P 10 93%+-3% 2.52 20 2
3 NTK-15 P 15 93%+-3% 2.31 30 2
4 NTK-20 P 20 93%+-3% 2.13 40 2
5 NTK-25 P 25 93%+-3% 2.01 50 2
6 NTK-30 P 30 93%+-3% 2.09 60 2
7 NTK-40 P 40 93%+-3% 1.81 80 2
8 NTK-50 P 50 93%+-3% 1.94 100 2
9 NTK-60 P 60 93%+-3% 1.62 120 2
10 NTK-80 P 80 93%+-3% 1.92 160 2
11 NTK-100 P 100 93%+-3% 1.83 200 2
Tsim lub hauv paus: Qhov siab: Tsawg dua lossis sib npaug li 500m; RH: Tsawg dua lossis sib npaug li 80%; Kub: 0 ​​degree -38 degree; Sau siab: 150Bar 40L Hom Lub tog raj kheej





Oxygen Generator rau Ntses Farm Key Features


Oxygen Generator For Fish Farm

Oxygen Supply Core:Dual-effect aeration, 1.5-3 meter aeration qhov tob, 30% siab dua cov pa oxygen efficiency dua li cov txheej txheem, tsa cov pa yaj hauv 1000㎡ ntses pas dej los ntawm 3mg / L mus rau ntau dua 8mg / L hauv 1 teev; ib chav tsev npog 500-2000㎡, 360℃kev pab them nqi tsis muaj qhov chaw tuag, tiv thaiv hauv zos tsis muaj oxygen.



Kev txuag hluav taws xob zoo:Ntshiab tooj liab tub ntxhais waterproof lub cev muaj zog, efficiency tshaj 90%, 20% -25% ntau zog-npaum li txhuas core motors, txuag 30-150 yuan ib hlis twg nyob rau hauv cov nqi hluav taws xob; xaiv tau ntse pib / nres, sib xws nrog yaj oxygen detectors, zam kev ua haujlwm tsis zoo.


Durable thiab Adaptable:Lub 304 stainless hlau thiab engineering yas lub cev yog corrosion-resistant thiab hnav-resistant, haum rau 5-8 xyoo nyob rau hauv dej tshiab / me ntsis brackish; lub cev muaj zog yog IP68 waterproof, leak- pov thawj thiab overheat-proof, nrog rau lub hauv paus hnyav rau kev ruaj ntseg, haum rau qhov hnyav ib puag ncig xws li pas dej, net tawb, thiab Hoobkas aquaculture.


Kev Ua Haujlwm thiab Kev Kho Mob:Tsis xav tau kev teeb tsa, tsuas yog qhib lub thawv, ntxiv dej thiab lub zog; los nrog 5-15 meter thickened waterproof cable; Cov ntsiab lus tseem ceeb yog detachable, tsuas yog xav tau cov cuab yeej yooj yim rau kev saib xyuas txhua hnub, tsis muaj cov neeg ua haujlwm xav tau.



Tus Nqi Aquaculture:Ua kom cov ntses thiab cw ciaj sia taus los ntawm 15% -30%, txhim kho kev hloov pauv hloov pauv hloov pauv los ntawm 10% -20%, tso cai rau kev ua lag luam ua ntej los ntawm 7-15 hnub, txo cov khoom tsis zoo xws li ammonia nitrogen, thiab txo qis kev pheej hmoo ntawm aquaculture thiab nqi.





FAQ


1. Dab tsi ntawm aquaculture scenarios yog lub tshuab hluav taws xob oxygen haum rau?
Nws yog dav siv tau rau cov pas dej ntses dej tshiab, cov cw hauv hiav txwv, cov pas dej hauv pas dej, cov pas dej qav, kev lag luam rov ua dej hauv dej, tawb aquaculture, thiab mov- ntses co- kab lis kev cai. Nws hloov mus rau ob lub pas dej me me thiab loj -tej dej hauv dej hiav txwv, thiab ua haujlwm ruaj khov nyob rau hauv qhov kub thiab txias, hnub los nag thiab lwm yam pa oxygen- ib puag ncig tsis txaus.


2. Yuav ua li cas xaiv tus qauv tsim nyog rau kuv cov ntses ua liaj ua teb?
Xaiv cov qauv raws li koj qhov chaw hauv pas dej thiab qhov tob dej: Rau 500-800㎡ pas dej, xaiv 0.75KW; 800-1200㎡ rau 1.5KW; 1200-1600㎡ rau 2.2KW; 1600-2000㎡ rau 3.0KW; thiab 2000-3000㎡ rau 5.5KW. Yog hais tias cov dej tob tshaj 2 meters los yog cov stocking ceev yog siab, nws raug nquahu kom xaiv ib tug qauv nrog lub hwj chim ntau dua los xyuas kom meej txaus oxygen mov.



3.Lub zog tiag tiag yog dab tsi - txuag hluav taws xob, thiab txuag hluav taws xob ntau npaum li cas hauv ib hlis?
Nruab nrog ntshiab tooj liab core motors, nws txuag 20% ​​-25% zog piv nrog cov zoo tib yam aluminium core motor oxygen generators. Kev ua haujlwm txhua hnub ntawm 8 teev ua piv txwv: tus qauv 0.75KW txuag txog 30 yuan / hli, 2.2KW qauv txuag 80-100 yuan / hli, thiab 5.5KW qauv txuag tau txog 150 yuan / hli. Qhov kev xaiv ntse pib / nres ua haujlwm tuaj yeem txo qis kev siv hluav taws xob tsis raug.


4.Qhov khoom siv tau ntev npaum li cas, thiab nws tuaj yeem tiv taus ntev - lub sij hawm immersion hauv dej?
Lub cev yog ua los ntawm 304 stainless hlau + engineering yas, thiab cov khoom tseem ceeb xws li impellers yog anti-corrosion thiab anti- hnav kho. Nws tuaj yeem muab tso rau hauv dej tshiab lossis dej khov me ntsis rau lub sijhawm ntev, nrog lub neej ua haujlwm ntawm 5-8 xyoo. Lub cev muaj zog muaj IP68 kev ntsuas dej tsis zoo, nrog kev tiv thaiv kev tawm tsam thiab kev tiv thaiv kub dhau, thiab tuaj yeem ua haujlwm ruaj khov hauv huab cua hnyav xws li cua daj cua dub.



5. Puas yog kev teeb tsa thiab kev saib xyuas nyuaj? Kuv puas xav tau cov neeg ua haujlwm tshaj lij?
Nws txais kev teeb tsa-dawb tsim-unbox, muab tso rau hauv dej, thiab txuas rau lub hwj chim siv, tsis muaj kev sib dhos nyuaj. Cov khoom siv thickened waterproof cable ua tau raws li qhov xav tau ntawm lub zog sib txawv. Cov khoom tseem ceeb yog detachable; Kev tu txhua hnub thiab hloov pauv tsuas yog xav tau cov cuab yeej yooj yim, thiab tsis tas yuav tsum muaj cov kws tshaj lij cov neeg ua haujlwm, uas txo cov nqi kho mob zoo heev.




Cim npe nrov: Oxygen Generator rau ntses ua liaj ua teb, Tuam Tshoj Oxygen Generator rau ntses ua liaj ua teb, lwm tus neeg, Hoobkas
